TECHNICAL DATA FOR THE BMW 3 SERIES TOURING PLUG-IN HYBRID.

^{1 ,}²
Powertrain type	Petrol – Plug-in Hybrid
Power in kW (hp)	215 (292) ³
Torque in Nm	420 ³
Transmission	8-speed, automatic
Drivetrain	Rear-wheel drive

¹
Cylinders	4
Displacement in cm³	1,998
Nominal power in kW (hp)/1/min	135 (184) / 5,000 - 6,500
Nominal torque in Nm/1/min	300 / 1,350 - 4,000

^{2 ,}⁴
(Nominal) power/30-minutes-power in kW (hp)	80 (109)
(Nominal) torque in Nm	265


Acceleration 0–100 km/h in s	6 ⁵
Top speed in km/h	230
Electric top speed in km/h	140

^{1 ,}⁶
Fuel consumption, combined WLTP in l/100km ⁷	1–0.9
CO2 emissions, combined WLTP in g/km ⁷	22–20
Energy consumption, combined WLTP in kWh/100 km ⁷	22.1–21.6
Electric range, WLTP in km ⁸	93–96
Pass-by noise in dB(A)	68 ¹²
Stationary noise level in dB(A) / 1/min	76 / 3,750 ¹²

⁹
Battery capacity in kWh	19.5
Maximum charging power AC in kW	11
Charging time AC 0–100% in h	2:15


4,713 mm
1,827 mm
1,448 mm
Length in mm	4,713
Width in mm	1,827
Height in mm	1,448
Width incl. mirrors (driver / passenger side) in mm	2,068
Wheelbase in mm	2,851
Vehicle curb weight in kg ¹⁰	1,970
Permissible gross weight in kg	2,420
Payload in kg	525
Optionally delivered with support for trailer load, braked, up to 12% / towbar download in kg ¹¹	1,500 / 75
Luggage capacity in l	410–1,420
Tank capacity in l	40

¹
Powertrain type	Petrol
Power in kW (hp)	135 (184)
Torque in Nm	300
Transmission	8-speed, automatic
Drivetrain	Rear-wheel drive

¹
Cylinders	4
Displacement in cm³	1,998
Nominal power in kW (hp)/1/min	135 (184) / 5,000 - 6,500
Nominal torque in Nm/1/min	300 / 1,350 - 4,000


Acceleration 0–100 km/h in s	7.6 ⁵
Top speed in km/h	230

^{1 ,}⁶
Fuel consumption, combined WLTP in l/100km	7.5–6.8
CO2 emissions, combined WLTP in g/km	170–153
Pass-by noise in dB(A)	66 ¹²
Stationary noise level in dB(A) / 1/min	86 / 3,750 ¹²


4,713 mm
1,827 mm
1,440 mm
Length in mm	4,713
Width in mm	1,827
Height in mm	1,440
Width incl. mirrors (driver / passenger side) in mm	2,068
Wheelbase in mm	2,851
Vehicle curb weight in kg ¹⁰	1,660
Permissible gross weight in kg	2,180
Payload in kg	595
Optionally delivered with support for trailer load, braked, up to 12% / towbar download in kg ¹¹	1,600 / 75
Luggage capacity in l	500–1,510
Tank capacity in l	59

¹
Powertrain type	Petrol – 48 Volt Mild-Hybrid
Power in kW (hp)	275 (374)
Torque in Nm	500
Transmission	8-speed, automatic
Drivetrain	All-wheel drive

¹
Cylinders	6
Displacement in cm³	2,998
Nominal power in kW (hp)/1/min	275 (374) / 5,500 - 6,500
Nominal torque in Nm/1/min	500 / 1,900 - 5,000


(Nominal) power/30-minutes-power in kW (hp)	8 (11) / -
(Nominal) torque in Nm	25


Acceleration 0–100 km/h in s	4.6 ⁵
Top speed in km/h	250

^{1 ,}⁶
Fuel consumption, combined WLTP in l/100km	8.7–8.1
CO2 emissions, combined WLTP in g/km	197–182
Pass-by noise in dB(A)	67 ¹²
Stationary noise level in dB(A) / 1/min	90 / 3,750 ¹²

⁹
Battery capacity in kWh	0.4


4,714 mm
1,827 mm
1,440 mm
Length in mm	4,714
Width in mm	1,827
Height in mm	1,440
Width incl. mirrors (driver / passenger side) in mm	2,068
Wheelbase in mm	2,851
Vehicle curb weight in kg ¹⁰	1,870
Permissible gross weight in kg	2,390
Payload in kg	595
Optionally delivered with support for trailer load, braked, up to 12% / towbar download in kg ¹¹	1,800 / 75
Luggage capacity in l	500–1,510
Tank capacity in l	59

¹
Powertrain type	Petrol
Power in kW (hp)	135 (184)
Torque in Nm	300
Transmission	8-speed, automatic
Drivetrain	Rear-wheel drive

¹
Cylinders	4
Displacement in cm³	1,998
Nominal power in kW (hp)/1/min	135 (184) / 5,000 - 6,500
Nominal torque in Nm/1/min	300 / 1,350 - 4,000


Acceleration 0–100 km/h in s	7.6 ⁵
Top speed in km/h	230

^{1 ,}⁶
Fuel consumption, combined WLTP in l/100km	7.2–6.8
CO2 emissions, combined WLTP in g/km	162–153
Pass-by noise in dB(A)	66 ¹²
Stationary noise level in dB(A) / 1/min	86 / 3,750 ¹²


4,713 mm
1,827 mm
1,440 mm
Length in mm	4,713
Width in mm	1,827
Height in mm	1,440
Width incl. mirrors (driver / passenger side) in mm	2,068
Wheelbase in mm	2,851
Vehicle curb weight in kg ¹⁰	1,660
Permissible gross weight in kg	2,180
Payload in kg	595
Optionally delivered with support for trailer load, braked, up to 12% / towbar download in kg ¹¹	1,600 / 75
Luggage capacity in l	500–1,510
Tank capacity in l	59

^{1 ,}²
Powertrain type	Petrol – Plug-in Hybrid
Power in kW (hp)	215 (292) ³
Torque in Nm	420 ³
Transmission	8-speed, automatic
Drivetrain	Rear-wheel drive

¹
Cylinders	4
Displacement in cm³	1,998
Nominal power in kW (hp)/1/min	135 (184) / 5,000 - 6,500
Nominal torque in Nm/1/min	300 / 1,350 - 4,000

^{2 ,}⁴
(Nominal) power/30-minutes-power in kW (hp)	80 (109)
(Nominal) torque in Nm	265


Acceleration 0–100 km/h in s	6 ⁵
Top speed in km/h	230
Electric top speed in km/h	140

^{1 ,}⁶
Fuel consumption, combined WLTP in l/100km ⁷	0.9
CO2 emissions, combined WLTP in g/km ⁷	21–20
Energy consumption, combined WLTP in kWh/100 km ⁷	21.9–21.4
Electric range, WLTP in km ⁸	94–97
Pass-by noise in dB(A)	68 ¹²
Stationary noise level in dB(A) / 1/min	76 / 3,750 ¹²

⁹
Battery capacity in kWh	19.5
Maximum charging power AC in kW	11
Charging time AC 0–100% in h	2:15


4,713 mm
1,827 mm
1,448 mm
Length in mm	4,713
Width in mm	1,827
Height in mm	1,448
Width incl. mirrors (driver / passenger side) in mm	2,068
Wheelbase in mm	2,851
Vehicle curb weight in kg ¹⁰	1,970
Permissible gross weight in kg	2,420
Payload in kg	525
Optionally delivered with support for trailer load, braked, up to 12% / towbar download in kg ¹¹	1,500 / 75
Luggage capacity in l	410–1,420
Tank capacity in l	40

1 WLTP Figures shown are for comparability purposes. Only compare fuel consumption and CO2 figures with other cars tested to the same technical procedures. These figures may not reflect real life driving results, which will depend upon a number of factors including the accessories fitted (post-registration), variations in weather, driving styles, fuel type and vehicle load.

2 For plug-in hybrid: Electric drive depending on battery charging level.

3 Composed of combustion engine drive (specified nominal value) and electric drive (up to specified nominal value). Electric drive depending on battery charging level.

4 For plug-in hybrid: At temperatures below freezing, the fully electric drive system is only available after a few kilometres of driving, once the battery has heated to operational temperature.

5 Provisional figures; any missing figures were unavailable at the time of publication.

6 For plug-in hybrid vehicles these figures were obtained using a combination of battery power and fuel, for battery electric vehicles these figures were obtained after the battery had been fully charged to 100%. Plug-in hybrid and battery electric vehicles require mains electricity for charging. WLTP figures shown are for comparability purposes. Only compare fuel consumption, CO2 and electric range figures with other cars tested to the same technical procedures. These figures may not reflect real life driving results, which will depend upon a number of factors including the starting charge of the battery, accessories fitted (post-registration), variations in weather, driving styles, fuel type and vehicle load.

7 For plug-in hybrid: Weighted, combined (EC AC Charge Weighted)

8 Range depends on various factors, in particular: individual driving style, route characteristics, outside temperature, heating/air conditioning, pre-conditioning.

9 The charging performance depends on the state of charge, ambient temperature, individual driving profile and use of auxiliary consumers. The ranges shown are based on the WLTP best case. The charging times apply to ambient temperatures of 23 degrees Celsius after a preceding drive and may differ depending on the usage behaviour.

10 The EC unladen weight refers to a vehicle with standard equipment and does not include any optional extras. The unladen weight includes a 90% full tank and a driver weight of 75 kg. Optional equipment may affect the weight of the vehicle, the payload and the top speed if the selected equipment has an impact on the vehicle's aerodynamics.

11 Trailer load depends on the vehicle options

12 The values measured in accordance with UN/ECE Regulation No. 51/EU Regulation 540/2014 are rounded.
